‹ VESTA® Control Panels

VESTA®|VESTA-047NNZ-SF1|2 YR WTY. Grade 2 IP + 4G SmartSeries Control Panel with Built-in Siren *Special order. 3-5 days lead time

✔ Grade 2 ✔ IP + 4G ✔ 640 zones ✔ 8 partitions ✔ Built-in siren ✔ SmartHomeSec app ✔ PIRCAM SF1 support ✔ Alexa and Google Home
SKU:
VESTA-047NNZ-SF1

A high-spec Grade 2 VESTA hub with IP and 4G, built for scalable installs and a modern app experience.

The VESTA® VESTA-047NNZ-SF1 is a SmartSeries Grade 2 control panel designed for professional, scalable VESTA installations. It combines TCP/IP and 4G communication with built-in siren, remote management and smart features, while keeping everyday control simple through the SmartHomeSec app experience.

For users, SmartHomeSec provides clear notifications and convenient remote control. For larger or more demanding sites, the platform supports up to 640 radio zones across 8 partitions and 240 users, making it suitable for everything from high-end residential through to multi-area small commercial projects. It also supports HD PIRCAM devices using the SF1 protocol, enabling visual verification workflows.

Why it works for homes and small businesses

  • One consistent experience

    SmartHomeSec supports app-based control and notifications, helping the system feel modern and easy to use.

  • Reliable communications

    IP and 4G reporting options provide flexibility across different site conditions.

  • Visual verification option

    SF1 PIRCAM support enables verification features where required.

Why it suits professional installation

  • Scales without changing platform

    High zone capacity, partitions and user support suit both small and larger multi-area jobs.

  • Remote management ready

    Designed for remote management plus web and app programming methods.

  • Automation expansion

    Supports home automation and can integrate Z-Wave devices using a separate dongle where required.

Key Features

  • Grade 2 SmartSeries platform

    EN50131 Grade 2, Environmental Class II.

  • IP and 4G communication

    TCP/IP and 4G module built in (optional WiFi pin referenced by manufacturer).

  • High capacity system

    Up to 640 radio zones, 8 partitions, 240 users.

  • Built-in siren

    Integrated siren (95dB stated by manufacturer).

  • SF1 support

    Supports HD transmission devices (PIRCAMS) with SF1 protocol and live visual verification.

  • Reporting methods

    CID/SIA, Email, SMS and Push Notification.

  • Voice assistant compatibility

    Compatible with Google Home and Alexa.

Key Specifications

  • Wireless frequency: 868MHz
  • Power supply: 12V, 1A
  • Operating temperature: -10°C to +45°C
  • Relative humidity: up to 85% (non-condensing)

Dimensions

  • 140 × 150 × 42 mm
